HV Inline valve, DN 40 ISO-KF, electro-pneumatic, PV 24 V DC, SS/FKM, "A"-dim. 130 mm
- Single acting, normally closed (air to open / spring to close)
- With elastomer seals for high vacuum operation
- Additional bellows segments increase the service life
- Can be operated in any orientation
- Additional O-ring materials available
-
AIVP-S04102
- Single acting, normally closed (air to open / spring to close)
- With elastomer seals for high vacuum operation
- Additional bellows segments increase the service life
- Can be operated in any orientation
- Additional O-ring materials available
- Delivery time: 5 weeks
Global-No. 2000035926
| Connection flange | DN 40 ISO-KF |
|---|---|
| Actuator | Electro-pneumatic |
| Bakeout temperature: actuator, pilot valve | 60 °C |
| Bakeout temperature: housing | 150 °C |
| Operating pressure min. | 1 · 10-8 hPa |
| Tightness | 1 · 10-9 mbar l/s |
| Seal | FKM |
| Differential pressure in opening direction | 1400 hPa |
| Differential pressure in closing direction | 1400 hPa |
| Pressure max. (absolute) | 1000 hPa |
| Compressed air (overpressure) | 6000 – 8000 hPa |
| Compressed air volume | 26 cm³ |
| Feedthrough |
|
| Input voltage(s) | 24 V DC |
| Inrush Power | 4.5 W |
| Housing | Stainless steel |
| Weight | 2 kg |
| Conductance value with molecular flow | 25 l/s |
| Closing/opening time | 1.25 s/1.5 s |
| Service life | 1000000 cycles |
| Control valve | Included |
| Temperature range | 20 – 150 °C |
| Type | HV Inline Valve |
| mm | |
|---|---|
| A | 130 |
| B | 145 |
| C | 76 |
