HV Inline valve, DN 50 ISO-KF, manual, SS/FKM, "A"-dim. 178 mm
- With elastomer seals for high vacuum operation
- Stainless steel body with welded diaphragm bellows
- Conductance continuously variable with handwheel (multi-turn)
- Fully retracting and opening
- Additional O-ring materials available
-
AIV-S05100
- With elastomer seals for high vacuum operation
- Stainless steel body with welded diaphragm bellows
- Conductance continuously variable with handwheel (multi-turn)
- Fully retracting and opening
- Additional O-ring materials available
- Delivery time: 4 weeks
Global-No. 2000035897
| Connection flange | DN 50 ISO-KF |
|---|---|
| Actuator |
Spindle Handwheel |
| Bakeout temperature: actuator | 60 °C |
| Bakeout temperature: housing | 150 °C |
| Operating pressure min. | 1 · 10-8 hPa |
| Tightness | 1 · 10-9 mbar l/s |
| Seal | FKM |
| Differential pressure in opening direction | 1400 hPa |
| Differential pressure in closing direction | 1400 hPa |
| Pressure max. (absolute) | 1000 hPa |
| Feedthrough |
Bellows Stainless steel |
| Housing | Stainless steel |
| Weight | 1.6 kg |
| Conductance value with molecular flow | 48 l/s |
| Service life | 100000 cycles |
| Type | HV Inline Valve |
| mm | |
|---|---|
| A | 178 |
| B | 157 |
| C | 75 |
| D | 89 |
