ULD 016 S, Linear motion feedthrough, manually actuated
- Hermetically sealed, suitable for UHV
- Bellows-sealed
- Direct manual push/pull actuation
- With setscrew
-
PF 630 010 -T
- Hermetically sealed, suitable for UHV
- Bellows-sealed
- Direct manual push/pull actuation
- With setscrew
- Delivery time: 3 weeks
Global-No. 2000026491
| Connection flange | DN 16 CF-R |
|---|---|
| Actuator |
|
| Resolution | 5 mm |
| Bakeout temperature max. | ≤ 300 °C |
| Load capacity radial: at max. stroke | 20 N |
| Load capacity: torsion | 0.2 nm |
| Mode of operation | Handle |
| Operating temperature | ≤ 300 °C |
| Tightness | 1 · 10-11 Pa m³/s |
| Pressure range | 1E-9 hPa – 0 hPa over pressure |
| Feedthrough |
|
| Mounting orientation | Arbitrary |
| Weight | 0.2 kg |
| Stroke | 25 mm |
| Material | Stainless steel |
| Service life | 10000 cycles |
| Shaft connection | M4 x 16 mm |
| Shaft load, axial: against atmosphere | 100 N |
| Shaft load, axial: against vacuum | 85 N |
