PPT 200 AR, DN 16 CF-F
- 1 · 10-4 – 1000 hPa
- High protection level for industrial applications
- Analog output and set points
-
PT R38 311
- 1 · 10<sup>-4</sup> – 1000 hPa
- High protection level for industrial applications
- Analog output and set points
- Delivery time: On request
Global-No. 2000006352
| Connection flange | DN 16 CF-F |
|---|---|
| Bakeout temperature at the flange | ≤ 150 °C |
| Seal |
|
| Pressure max. | 4 · 103 hPa |
| I/O interfaces | RS-485, analog 0 – 10 V |
| Input voltage(s) | 24 V DC |
| Weight | 0.22 kg |
| Filament | Tungsten |
| Power consumption max. | 3.2 W |
| Materials in contact with media |
|
| Measuring range | 1E-4 – 1E3 hPa |
| Accuracy of measurement in range 1 | 10 % (2E-3 hPa – 2E1 hPa) |
| Accuracy of measurement in range 2 | 30 % (2E1 hPa – 1E3 hPa) |
| Measurement cable length min. | 100 m |
| Measuring method |
|
| Measuring cycle | 10 ms |
| Relay: Number | 2 pcs. |
| Relay: Switching voltage | 30 V DC / 49 V AC |
| Protection degree |
|
| Ambient temperature | 5 – 60 °C |
| Repeatability in range 1 | 2 % (2E-3 hPa – 1E1 hPa) |
