EVR 116, Gas control valve
- High gas throughput
- Very large control range
- With integrated motor control electronics
-
PF I39 931 A
- High gas throughput
- Very large control range
- With integrated motor control electronics
- Delivery time: 1-3 days
Global-No. 2000025829
| Connection flange | DN 16 ISO-KF |
|---|---|
| Control | RVC 300 or IF 200 |
| Actuator |
|
| Bakeout temperature: actuator | 60 °C |
| Bakeout temperature: housing | 80 °C |
| Operating pressure min. | 1 · 10-8 hPa |
| Tightness | 1 · 10-10 Pa m³/s |
| Seal |
|
| Dosing sleeve | Fluoroplastomer |
| Pressure max. (absolute) | 2500 hPa |
| Input voltage(s) | 24 V DC |
| Max. controllable gas flow | 1.25 · 103 hPa·l/s |
| Min. controllable gas flow | 5 · 10-6 hPa·l/s |
| Housing |
|
| Weight | 0.75 kg |
| Power consumption max. | 12 W |
| Closing/opening time | 3 s/4 s |
| Control voltage | 0 – 10 V DC |
| Type | Gas control valve |
| Ambient temperature | 5 – 40 °C |
