OmniControl 200, table unit
- Universal control unit for all products with Pfeiffer Vacuum RS-485 protocol
- Easy to operate on 3.5'' touchscreen display
- Uncomplicated data acquisition and processing between Pfeiffer Vacuum units
- The respective modules define the scope of functions
-
PE E52 100 0
- Universal control unit for all products with Pfeiffer Vacuum RS-485 protocol
- Easy to operate on 3.5'' touchscreen display
- Uncomplicated data acquisition and processing between Pfeiffer Vacuum units
- The respective modules define the scope of functions
- Delivery time: On request
Global-No. 2000026704
| Output voltages | DC: 24 V |
|---|---|
| Output current | 11.4 A |
| Input voltage(s) | 100 – 240 V AC (±10 %), 50/60 Hz |
| Weight | 2.1 kg |
| Power consumption max. | 300 W |
| Measuring channel | 1 pcs. |
| Module Slot 1 | Data |
| Module Slot 2 | Gauge/IO |
| Mains frequency compatibility |
|
| Protection degree | IP20 |
| Ambient temperature | 0 – 50 °C |
